Fujifilm 4300 Mini
High-performance 1.6" digital inkjet print system with Samba printhead technology
The Fujifilm 4300 Mini represents the next generation of compact digital inkjet printing technology, featuring advanced Samba printhead technology for exceptional print quality and reliability.
With a 1.6" (40mm) print width, this system is perfect for small to medium format applications requiring high-resolution printing with both AQ and UV ink compatibility.
Key Features
- 1.6" (40mm) print width for compact applications
- Advanced Samba printhead technology
- AQ and UV ink compatibility
- Multi-head system capability (1-4 heads per controller)
- Complete system with integrated controller
Interested in Fujifilm 4300 Mini?
Contact us for pricing, specifications, and system configuration options.
Get QuoteTechnical Specifications
Print Specifications
| Configurations | Roll fed, sheet fed, inline/nearline, single or multiple printheads |
| Resolution | Up to 1200 DPI |
| Dimensions | 22.87" × 7.5" × 3.6" (581 × 190.5 × 92 mm) |
| Speed | Up to 1800 fpm (548 m/min)* |
| 📏 Print Width | 1.6" (4.1 cm) per printbar |
| Input Format | TIFF, PDF |
| Smallest Font | 2 pt (4 pt knockout)* |
| 💧 Drop Size | 2.4 or 3.5 pL / 13 pL (Native / Max) |
Control Cabinet
| Dimensions | 30.1" × 8.8" × 30" (764.7 × 223.4 × 762 mm) |
| Weight | 86 lbs (39 kg) |
| Input | Universal 110–240 VAC (Single phase 50/60 Hz) |
| 🔌 I/O | Remote and client |
| ⚡ Max Current Draw | 6.3A |
| Max Printbar Support | 4 |
| 〰️ Waveform | 4 independent |
🖥️ PC/Software
| 🔌 PC Interfaces | GUI or remote application over IP |
| 🪟 Control System | Windows® 10 GUI (Windows 11 maybe available) |
| Variable Data | Yes |
🌍 Flexibility for a Broad Range of Markets
The Mini 4300 is configurable with one to four individually controlled printbars. The system provides single-pass printing in monochrome or process color for a wide variety of production applications, including:
Key Points
High Performance
1200 DPI or up to 1800 FPM
Compact Design
Small size and portable
Scalable
Expandable system
Color Options
2 bit grayscale and CMYK
Configuration
Single or multi-lane
Nozzle Redundancy
Fujifilm's SAMBA® Print Systems
Fujifilm's SAMBA® print systems have 32 rows of nozzles per printhead, which provides redundancy in the event of nozzle loss.
This advanced redundancy technology ensures consistent print quality and reliability, even if individual nozzles fail, making it ideal for high-volume production environments where uptime is critical.
System Includes
Print System price includes: Printbars, data/electric/fluid controller, Print Engine Control Software, print computer, monitor, keyboard, variable data RIP software (requires PDF input), encoder, trigger and all necessary fluid and electrical interconnects.
Multi-Head Discount
As one controller computer system can drive multiple heads, if you want 1, 2, 3, or 4 units on the same system, the prices are discounted to represent one controller and up to 4 printheads.
Applications
Small Format Labels
Perfect for small label printing and marking applications
Product Marking
Ideal for product identification and serial number printing
Variable Data
High-quality variable data printing with PDF input
Additional Services
We can assist with integration, installation, commissioning, training, maintenance, and any other services related to the Fujifilm 4300 Mini.
Samba Printhead Technology
Advanced Technology
The Fujifilm 4300 Mini utilizes the same advanced Samba printhead technology featured in our XBAR Printhead systems, ensuring consistent, high-quality printing across all applications.
This proven technology delivers exceptional droplet control, reliability, and performance for demanding industrial printing applications.
Perfect Replacement
The 4300 Mini is the ideal replacement for 1" and 2" Kodak Versamark printheads, offering modern technology with improved performance and reliability.
Our team can help you transition from legacy systems to this advanced digital inkjet solution while maintaining your production requirements.
